PROSOFT MVI56E-MNETC 16通道

核心技术

●  软件平台技术

结合IEC61131-3的可编程逻辑控制，PLCOpen运动控制算法，以及机器视觉处理算法

●  实时/总线系统

基于Linux的实时操作系统优化技术，gLink-II，EtherCAT，PROFINET，CANOpen，EtherNet IP，Modbus

●  互联互通

设备层，OPC UA协议，面向IT层的数据交互接口，支持MQTT协议的主流工业云实现互联

●  特殊要求

针对PLC特殊行业领域，双机热备，冗余，安全PLC等模块研发

无限扩展

■  gLink-II 千兆等环网

● 实现12轴 一 48轴硬实时高速运动控制， 控制周期250us 一 1ms

● 支持点位、Jog、电子齿轮、电子凸轮、4轴直线插补、2D/3D圆弧插补、螺旋线插补、刀向跟随、速度前瞻等运动控制功能

● 强大的I/O扩展功能，支持2048个I/O点

● 支持主站间高速数据同步，热备，控制器冗余

■  Super-EtherCAT

● 实现64轴硬实时高速运动控制，控制周期1ms

● 支持点位、Jog、电子齿轮、电子凸轮、4轴直线插补、2D/3D圆弧插补、螺旋线插补、刀向跟随、速度前瞻等运动控制功能

● 强大的I/O扩展功能，支持65535个I/O点

● 内置UPS，可支持掉电保存数据

 If the linkage to engine is correctly adjusted, the engine will shut down.efer to Figure 3-1 with the text to better understand the operation of the UG Lever governor. This schematic diagram is of a basic design and does not include any auxiliary equipment. This description is based on speed changes resulting from load changes. However, the same sequence of governor movements would occur if the governor speed setting were changed by repositioning the speed control linkage. Decrease in Load Assume the prime mover is running on-speed. The flyweights are in a vertical position for normal steady-state operation. The control land of the pilot valve plunger (14) is centered over the control port of the rotating bushing (5304-MBP-PDPM). This stops the flow of pressure oil through the bushing (15) control port. As a result, there is no movement of the power piston (7) and no movement of the governor output shaft (6).

 The speed droop assembly (Figure 3-2) consists of a speed droop lever assembly, a speed droop cam, and a speed droop link assembly which, when set, changes the compression of the speed setting spring as the governor output shaft rotates. For illustrated parts and part reference numbers of the optional speed droop assembly, see Figure 6-1.If it is desired that the engine be shut down from the throttle position, the UG Lever governor can be equipped with a shutdown rod (Figure 3-3) operating as follows: When the throttle is moved toward the shutdown position, the speeder plug rises, contacting the nut on the shutdown rod. Further movement lifts the shutdown rod, lifting speeder rod and inner end of floating lever, thus raising the pilot valve plunger and uncovering the control port in the pilot valve bushing. This permits oil under the power piston to flow to sump. Oil pressure on top of the power cylinder forces the power piston down to the zero fuel position.

Infinite expansion

GLink-II Gigabit Ring Network

Implement 12 axis to 48 axis hard real-time high-speed motion control, with a control cycle of 250us to 1ms

● Supports motion control functions such as point positioning, Jog, electronic gears, electronic cams, 4-axis linear interpolation, 2D/3D arc interpolation, spiral interpolation, tool direction following, and speed foresight

Powerful I/O expansion function, supporting 2048 I/O points

● Support high-speed data synchronization between main stations, hot standby, and controller redundancy

Super EtherCAT

Implement 64 axis hard real-time high-speed motion control with a control cycle of 1ms

● Supports motion control functions such as point positioning, Jog, electronic gears, electronic cams, 4-axis linear interpolation, 2D/3D arc interpolation, spiral interpolation, tool direction following, and speed foresight

Powerful I/O expansion function, supporting 65535 I/O points

● Built in UPS that supports power-off to save data
