PROSOFT MVI56E-MNETXT 可编程控制器

警告：MVI56E-SIE当背板电源打开时插入或卸下模块时，可能会发生电弧。电弧可能会因以下原因造成人身伤害或财产损失： 向系统的执行器发送错误信号，导致机器意外运动或失去过程控制 在危险环境中引发爆炸。继续操作前，请确认电源已断开或该区域无危险。反复的电弧会导致模块及其配对连接器上的触点过度磨损。触点磨损可能会产生电阻，从而影响模块的工作。1将模块与顶部和底部导轨对齐，然后将其滑入机架，直到模块牢固地靠在背板连接器上。MVI56E-SIE 2用力但稳定地推动，将模块卡入到位。3检查模块顶部和底部的固定夹是否牢固地位于机架的锁定孔中MVI56E-SIE。4打开电源。注意：如果模块插入不当，系统可能会停止工作，或者可能出现不可预测的行为。

MVI56E-SIE

如果您尚未安装和配置MVI56E-SIE处理器和电源，请在安装MVI56E-SIE模块之前进行安装和配置。有关安装说明，请参阅罗克韦尔自动化产品文档。警告：安装此或任何其他电子设备时，必须遵守所有安全说明。不遵守安全程序可能导致硬件或数据损坏，甚至人员重伤或死亡。在安装或维修设备之前，请参阅计划连接的每个设备的文档，以验证是否有适当的安全程序。检查跳线的位置后，将MVI56E-SIE插入ControlLogix机箱。使用罗克韦尔自动化推荐的相同技术来拆卸和安装MVI56E-SIE模块。您可以在机箱通电和系统运行时安装或卸下MVI56E-SIE系统组件。但是，请注意以下警告。

Worn contacts may create electrical resistance that can affect module operation. 1 Align the module with the top and bottom guides, and then slide it into the rack until the module is firmly against the backplane connector. 2 With a firm but steady push, snap the module into place. 3 Check that the holding clips on the top and bottom of the module are securely in the locking holes of the rack. MVI56E-SIE 4 Turn power ON. Note: If you insert the module improperly, the system may stop working, or may behave unpredictably.

 Use the same technique recommended by Rockwell Automation to remove and install ControlLogix modules. You can install or remove ControlLogix system components while chassis power is applied and the system is operating. However,MVI56E-SIE  please note the following warning. Warning: When you insert or remove the module while backplane power is on, an electrical arc can occur. An electrical arc can cause personal injury or property damage by: § sending an erroneous signal to your system's actuators causing unintended machine motion or loss of process control § causing an explosion in a hazardous environment Verify that power is removed or the area is non-hazardous before proceeding. Repeated electrical arcing causes excessive wear to contacts on both the module and its mating connector.

If you have not already installed and configured your ControlLogix processor and power supply, please do so before installing the ILX56-MM module. Refer to your Rockwell Automation product documentation for installation instructions. Warning: You must follow all safety instructions when installing this or any other electronic devices. Failure to follow safety procedures could result in damage to hardware or data, or even serious injury or death to personnel.MVI56E-SIE Refer to the documentation for each device you plan to connect to verify that suitable safety procedures are in place before installing or servicing the device. After you have checked the placement of the jumper,MVI56E-SIE insert ILX56-MM into the ControlLogix chassis.
